Ready to Get Your VFD Solution?
Whether you need a single drive or a complete system, we have the VFD products and engineering support to ensure your project's success.
High Performance VFD
Achieve precise motor control, superior energy efficiency, and reliable operation.
Unlock the full potential of your machinery with our High-Performance AC Variable Frequency Drives (VFDs). Engineered for the most demanding industrial applications, these AC drives provide unparalleled precision in speed and torque control for any AC motor. Delivering superior dynamic response, a wide speed range, and robust overload capabilities, our VFDs enhance productivity, improve product quality, and ensure operational reliability.
Understanding High Performance VFD
The Core of High-Performance Motor Control
At the heart of a high-performance VFD lies its advanced control algorithm. Unlike standard drives that primarily use V/F control for simple applications, our high-performance models leverage sophisticated vector control technology. This method creates a precise mathematical model of the AC motor, allowing for independent and dynamic control over both motor flux and torque, similar to the performance of a DC drive but with the reliability of an AC induction motor.
Key Features Defining Our High-Performance VFDs
Our high-performance variable frequency drives are engineered with a comprehensive suite of features to maximize operational output and efficiency. These advanced AC drives deliver exceptional torque across a wide speed range, from precise low-speed control to dynamic high-frequency outputs. They feature rapid dynamic speed response for agile acceleration and deceleration, ensuring precise regulation regardless of load conditions. Built for versatility, our drives seamlessly control both standard AC induction and high-efficiency permanent magnet motors, offering robust overload capacity to handle demanding duty cycles. Each drive integrates advanced safety features like Safe Torque Off (STO), solidifying our commitment to a powerful, reliable, and adaptable motor control solution for your most critical applications.
Comprehensive Industrial Protection
Applications That Require Peak VFD Performance
Why Invest in Our High-Performance Industrial VFDs?
Uncompromising Performance
We focus on delivering tangible results: faster cycle times, tighter process control, and higher product quality. Our advanced vector control algorithms ensure your motors perform at their absolute peak. Our entire range of high-performance applications has been developed by capitalizing on the global growth trends of electrification and digitalization to help our customers manage power more efficiently, today and well into the future.
Built for Industrial Realities
Our drives feature a robust design with conformal coatings on PCBs to withstand harsh industrial environments. High short circuit ratings and comprehensive protection functions safeguard the VFD and your motor, ensuring maximum uptime.
Simplified Integration and Use
Despite their advanced capabilities, our VFDs are designed for ease of use. A modern touchscreen interface with consolidated contextual menus and intuitive parameter structure simplifies commissioning. The design relies on the same parameter structure and fieldbus configuration across models, reducing the learning curve for your team.
Trusted for Industrial AC VFDS
Explore our comprehensive High Performance VFD product lines. Find the perfect drive for your industrial, commercial, or residential application.
YC-1610 High Performance VFD
A versatile and high-performance drive engineered for a broad range of industrial applications. It offers precise motor control through its advanced Sensorless Vector Control and standard V/F modes, making it an ideal and cost-effective solution for machinery requiring dynamic speed and torque regulation up to 55kW.
Technical features
YC-5000 High Performance VFD
Our premier high-performance VFD, designed for the most demanding and complex applications. It supports full closed-loop control with an encoder for ultimate precision, and can manage a vast range of motor powers up to 1000kW. This makes it the definitive choice for high-power cranes, extruders, and other critical systems that require the highest level of speed and torque accuracy.
Technical features
Complete Range of Configurations
This table provides an overview of the typical technical specifications for our high-performance VFD series
| Parameter | Specification / Capability |
|---|---|
| Control Modes | V/F Control, Sensorless Vector Control (SVC), Closed-Loop Flux Vector Control (FVC) |
| Power Range | 0.75 kW – 500+ kW (1 HP – 700+ HP) |
| Input Voltage | Three-Phase (3 Phase) AC 220V, 380V - 480V |
| Output Frequency | Vector Control: 0 – 300 Hz; V/F Control: 0 – 3000 Hz |
| Encoder Feedback Support | ABZ Incremental Encoder, Resolver, and more via accessible option card slots |
| Overload Capacity | Heavy-Duty (G-Type): 150% for 60s; 180% for 3s |
| Torque Response | < 10ms in Closed-Loop Vector Control mode |
| Communication Protocols | Standard: Modbus RTU; Multiple onboard protocols and options for Profinet, Modbus TCP |
Expert VFD Selection and Support
Selecting the optimal VFD requires careful consideration of your motor specifications, application requirements, environmental conditions, and performance objectives. Our technical team provides comprehensive support throughout the selection and implementation process.
We assist with:
- Motor-to-drive compatibility verification
- Load profile analysis and drive sizing
- Application-specific configuration recommendations
- Installation planning and commissioning support
- Troubleshooting and technical consultation
Frequently Asked Questions (FAQs)
A high-performance VFD uses more advanced processing power and sophisticated control algorithms, like flux vector control, to provide significantly better speed regulation, higher torque at low speeds, and faster dynamic response compared to standard V/F-based VFDs.
Yes, our high-performance variable frequency drives are designed to control both standard AC induction motors and high-efficiency permanent magnet synchronous motors, giving you flexibility in your machine design and motor selection.
Absolutely. Our VFD’s parameter structure and support for various industrial communication protocols are designed to make transitions straightforward. We provide support to help you migrate from legacy systems, ensuring a smooth and efficient upgrade process.
A closed-loop system, using an encoder for feedback, is necessary for applications that require the highest degree of precision. This includes machinery needing exact speed synchronization (master-follower systems), precise positioning tasks, and maintaining constant torque at zero speed, such as in crane applications.
While all VFDs save energy by matching motor speed to load demand, a high-performance drive further optimizes efficiency. Its precise control minimizes wasted energy during acceleration and deceleration and operates the motor at its most efficient flux level for any given torque, leading to additional energy savings.
Yes, our high-performance VFDs excel in multi-motor applications. With advanced vector control and optional closed-loop feedback, they ensure precise speed and torque synchronization, crucial for complex systems like web handling or multi-section conveyors.
